HD-LDR-II Thermal Conductivity Tester Laser Flash Method

Brand Name:	HAIDA
Model Number:	HD-60082
MOQ:	1 Set
Price:	Negotiable
Packaging Details:	Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,,In cash, escrow

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China (Mainland)

Certification:

ISO,CE,

Test Range:

0.005-300W/(m*K)

Test Mode A:

Room Temperature

Test Mode B:

RT~120℃ (Required Other Temp. Control Device)

Probe Diameter A:

7.5 Mm

Probe Diameter B:

15 Mm

Resolution:

±3%

Repeatability Error:

≤3%

Test Time:

5~160 Sec

Power:

AC 220V

External Dimension(W*H*D):

50*41*20 Cm

Supply Ability:

300 Sets per Month Haida

Highlight:

HD-LDR-II Thermal Conductivity Tester

Laser Flash Thermal Conductivity Tester

Product Description

HD-LDR-II Thermal Conductivity Tester (Laser Flash Method)

Description:

This instrument is suitable for measuring the thermal diffusivity and thermal conductivity of high thermal conductivity solid materials, such as metals, graphite, etc., in accordance with the national standard GB/T 22588-2008 "Flash Method for Measuring Thermal Diffusivity or Thermal Conductivity" and ASTM E 1461--2001 "Flash Method for Determining Thermal Diffusivity Test Method". Test principle: Thin samples are irradiated by high-intensity short-time energy pulses. The front side of the sample absorbs the pulse energy to increase the back temperature. The back temperature change is recorded. The time required for the back temperature of the sample to rise to half of the maximum value after receiving the light pulse irradiation (also called the half-heating time) is used to quickly calculate its thermal diffusivity α and thermal conductivity l using a computer through a special mathematical model. Our company's transient laser method thermal conductivity tester is suitable for testing high thermal conductivity materials such as metals, graphite, graphene, silicon carbide, etc. It has the advantages of fast measurement speed and accurate measurement results. It has a high cost-effectiveness and meets the production, quality inspection, and research and development needs of related industries.

ASTM D5470-12 Rubber Thermal Conductivity Tester Equipment for Plastic Testing Material Analyzer 0

Technical Parameters

tem	Parameters
Thermal conductivity measurement range	0.1~2000w/m.k, resolution: 0.1w/m.k
Sample size	Φ12×(0.1~5)mm, square=10x10mm, thickness 1~3mm
Laser source power	200W adjustable
Test accuracy	±3%
Repeatability	Deviation between two measurements <±3%
Testing results	The computer can simultaneously calculate multiple thermal parameters such as thermal diffusion coefficient (thermal conductivity), specific heat capacity, etc.
Control mode	Can communicate with general computers, use fully automatic test software, quickly and accurately analyze the test process parameters and output reports for samples
Power	1∮ AC 220V 50HZ 500W

ABOUT HAIDA

HD-LDR-II Thermal Conductivity Tester Laser Flash Method

Why choose us?

1.Design & Production : Solution Consultation for each order
Recommend the most cost -performance machine
Research & Develop the suitable one for Special- designed Model.
2.Shipping & Delivery: One-Stop Service
Production- Deliver to your door - Installation & Training- Technical Support
3.Warranty
1 year warranty with lifetime technology support
4.After-Sale Service
React within 2 Hours
Video inspection & on-site service combined

FAQ

Q: How about your warranty?

A: Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, if it's necessary, our engineers may go to your place for better service.

Q: What is the order process?

A: Get Inquiry - Send the Quotation - Confirm the requirements - Order confirming - Payment - production - testing and debugging- packing - Confirm with customer about the necessary documents- Arrangement the Delivery - Send the product out - Customer Receiving - After Service.

Q: Can we visit your factory before order?

A: Yes, we warmly welcome and sincerely invite you and your team to visit our factory, we will help to arrange hotel and pick up you from airport.

Q: Do you accept customization service?

A: Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don't hesitate to tell us your requirement, we will do our best to meet your needs.
