Automatic Salt Spray Environmental Test Chambers With Over Pressure Protection

Brand Name:	HAIDA
Model Number:	HD-E808-200
MOQ:	1 Set
Price:	Negotiable
Packaging Details:	ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China (Mainland)

Certification:

ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC

Brine Tank Capacity:

40L

Test Chamber Temperature:

Salt Spray Method ( NSS ACSS ) 35±1°C Corrosion-resistant Testing Method ( CASS ) 50±1°C

Power:

AC220V , 30A

Accessories:

Testing Salt/ Measuring Tank/ Equipment Each 1 Set

Inner Box Size ( L×W×H ):

200×100×60 Cm

Outside Box Size ( L×W×H ):

270×150×150 Cm

Supply Ability:

300 Sets per Month Haida

Highlight:

environmental testing equipment

humidity temperature test chamber

Product Description

Automatic Salt Spray Environmental Test Chambers With Over Pressure Protection

Specifications:

Salt Spray Testing Machine
1 . Durable hard PVC construction ;
2 . reservoir with mixing system on stand

Salt Spray Testing machine adapted to the surface treatment of various materials , including paint , electroplating , organic and inorganic coating , anode processing , antirust oil and so on , after these anti-corrosive treatment to test the corrosion resistance of their products .

Automatic Salt Spray Environmental Test Chambers With Over Pressure Protection 0

Specifications:

Model	HD-E808-200
Internal Size (WDH)	20001000600mm
External Size (WDH)	270015001500mm
Equipment Material	P.V.C rigid plastic plate, thickness 8mm
Sample tray	Diameter 10mm glass fiber rod, anti-rust V-shape plastic steel to make sure sample in 15~30 degree inclined
Temperature Range	Room temperature ~ 55℃
Temperature Fluctuations	≤±0.5℃
Temperature Uniformity	≤±2℃
Temperature Precision	±1℃
Spraying method	Continuous and Periodic spray type
Test Chamber Temperature	Salt Spray Method (NSS ACSS)35±1℃ Corrosion-resistant Testing Method (CASS) 50±1℃
Saturated air Barrel Temperature	Salt Spray Method (NSS ACSS)47±1℃ Corrosion-resistant Testing Method (CASS) 63±1℃
Brine Temperature	35℃±1℃
Spray Quantity	1.0~2.0 ml / 80cm2 / hr
PH value	Salt Spray Method (NSS ACSS6.5~7.2) Corrosion-resistant Testing Method(CASS)3.0~3.2
Lab Volume	1200L
Brine Tank Capacity	40L
Multiple Safety Protection Devices	Current discharge protection, over pressure protection, over temperature protection, over load fuse protection
Accessories	Testing Salt / Measuring tank / Spray Nozzle x 1 set
Air source	Air pump (provided by buyer)
Test criteria	ASTM B117-08, ISO 9227...

Automatic Salt Spray Environmental Test Chambers With Over Pressure Protection 1
