Product Details:
Payment & Shipping Terms:
|
| Lab Volume: | 270L | Brine Tank Capacity: | 25L |
|---|---|---|---|
| Outside Box Size ( L×W×H ): | 141×88×128 Cm | Saturated Air Barrel Temperature: | Salt Spray Method ( NSS ACSS ) 47±1°C Corrosion-resistant Testing Method ( CASS ) 63±1°C |
| Inner Box Size ( L×W×H ): | 90×60×50 Cm | PH: | Salt Spray Method ( NSS ACSS6 . 5~7 . 2 ) Corrosion-resistant Testing Method ( CASS ) 3 . 0~3 . 2 |
| High Light: | humidity temperature test chamber,environmental testing machine |
||
Salt Spray Corrosion Resistant Environmental Test Chambers For Surface Treatment
salt spray test chamber brochure
Product Description:
Salt Spray Test Chamber adapted to the surface treatment of various materials , including paint , electroplating , organic and inorganic coating , anode processing , antirust oil and so on , after these anti-corrosive treatment to test the corrosion resistance of their products .
Specifications:
Salt Spray Corrosion Resistant Environmental Test Chambers For Surface Treatment
1 . Durable hard PVC construction ;
2 . reservoir with mixing system on stand
Features:
1. Local temperature and humidity inside and outside the box are used for A-level gray high-corrosive PVC, for salt spray, copper acetate, and other test specifications Test
2. It uses the A-level German imports of gray PVC material.
3. It uses sophisticated Class A gray PVC material designed "V" shape long, products tested by the 15 ° -30 ° angle be adjusted.
4. It uses a 5mm thick transparent imported high toughness PVC board, bending method designed to cover 100 degree ridge-type transparent with power failure memory function of time, so after the original call time to complete the remaining time of the experimental work, with a double over-temperature protection, water shortage warning, ensure safety
5. According to JIS, ASTM, CNS, GB standard parameter setting operation.
Experiment method:
| GB / T2423.17-2008 | salt spray test method |
| GB / T 2423.18-2000 | "basic procedures for electric and electronic products Test Ka" |
| GB / T10125-1997 | Corrosion tests in artificial atmospheres - salt spray test |
| GB / T10587-2006 | salt spray test chamber technical conditions |
| GB10593.2-1990 | electric and electronic products environmental parameters measurements |
| GB / T1765-1979 | Determination of resistance to humidity, salt spray, weather resistance (artificial acceleration) of the film prepared test |
Main Technical Parameter:
| items | Specification |
| Inner Box Size ( L×W×H ) | 90×60×50 cm |
| Outside Box Size ( L×W×H ) | 141×88×128 cm |
| Equipment Material | Both inside & outside shell adopt imported P . V . C rigid plastic board , and tank cover uses imported transparent P . V . C . rigid plastic board |
| Temperature Range | 35°C~55°C |
| Temperature Fluctuations | ≤±0 . 5°C |
| Temperature Uniformity | ≤±2°C |
| Temperature Precision | ±1°C |
Test Chamber Temperature |
Salt Spray Method ( NSS ACSS ) 35±1°C Corrosion-resistant Testing Method ( CASS ) 50±1°C |
| Saturated air Barrel Temperature | Salt Spray Method ( NSS ACSS ) 47±1°C Corrosion-resistant Testing Method ( CASS ) 63±1°C |
| Brine Temperature | 35°C±1°C |
| Spray Quantity | 1 . 0~2 . 0 ml / 80cm2 / hr |
| PH | Salt Spray Method ( NSS ACSS6 . 5~7 . 2 ) Corrosion-resistant Testing Method ( CASS ) 3 . 0~3 . 2 |
| Lab Volume | 270L |
| Brine Tank Capacity | 25L |
| Power | AC220V , 15A |
| Multiple Safety Protection Devices | Current discharge protection , over pressure protection , over temperature protection , over load fuse protection |
| Accessories | Testing Salt/ Measuring tank/ Equipment each 1 set |
| Standard | CNS : 3627 , 3385 , 4159 , 7669 , 8886 ; JIS : D0201 , H8502 , H8610 , K5400 , Z2371 ; ISO : 3768 , 3769 , 3770 ; ASTM : 8117 , B268 |
(The table parameters for the company Standard Model parameters, we support customer customization parameters)
