Automatic Simulated Environmental Water cooling Xenon Weathering Test Chamber

Brand Name:	HAIDA
Model Number:	HD-E711-1
MOQ:	1 Set
Price:	Negotiable
Packaging Details:	ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China (Mainland)

Certification:

CE,ISO

Internal Dimension (W*D*H):

800*800*800mm

External Dimension (W*D*H):

1450*1500*2000mm

Internal Chamber Material:

SUS 304 # Stainless Steel, Anti-rust, Easy To Clean

Outer Chamber Material:

Stainless Steel

Humidity Range:

50%-90%

Irradiated Intensity:

0.35±0.02w/m²at 340nm

Black Panel Temperature:

65±3℃

Filter:

Daylight Filter

Supply Ability:

30 Sets per Month Haida

Highlight:

cooling Xenon Uv Test Chamber

Uv Weathering Test Chamber

AC380V Uv Test Chamber

Product Description

Automatic Simulated Environmental Water Cooling Xenon Weathering Test Chamber

Main Feature:
1, Ventilation system: Automatic controlled by temperature controller, and inner chamber cooled by refrigerating system
2, Back panel thermometer: adopt wired transmission technology, which highly improve the control accuracy.
3, Temperature sensor: PT100 platinum resistance thermocouple.
4, Equip with intelligent temperature and humidity controller, with PID adjustment and rapid self-turning. It can set several parameters to do cyclic test, directly digital temperature display for easy reading.
5, Multiple protective devices: Over temperature protection, water leakage alarm, over pressure of compressor, electricity leakage protection, alarm and auto power offer protection. In order to protect Xenon light, the light will turn off automatically once open the door.
Automatic Simulated Environmental Water cooling Xenon Weathering Test Chamber 0
Main Parameter

Item	Specification
Internal Dimension (WDH)	800800800mm
External Dimension (WDH)	145015002000mm
Inner chamber material	SUS 304 # Stainless Steel, Anti-rust, easy to clean
Outer chamber material	Stainless steel
Chamber Temperature	40±3℃
Temperature Uniformity	≤3℃
Blank panel temperature	65±3℃
Humidity Range	50%-90%
Irradiated intensity	0.35±0.02w/m²at 340nm
Xenon lamp power	6.5KW water-cooled xenon lamp x 1pc
Control system	PLC controller, touch screen
Distance from specimen to arc center	250~300mm, Effective exposure area 6400cm2
Max. Sample dimension	200*90mm Thickness＜20mm
Filter	Daylight filter
Door seal	Silicone rubber seal
Temperature sensor	PT100 high precision temperature sensor
Air circulation system	Stainless steel centrifugal rotor vane to improve the uniformity of temperature and humidity
Cooling ventilator	Automatic controlled by temperature controller, and inner chamber cooled by refrigerating system
Cooling ventilator	France Tecumseh compressor
Power	AC380V, 50Hz, three phase
Safety Protection	Over heat protection for fan, Over load protection for cooling system, Over pressure protection for cooling system, Over temperature protection, Over heat and over flow protection for water pump, Leakage protection, Water shortage protection, Auto stop after failure warning
