50Hz Medical Face Mask Bacterial Filtration Efficiency Tester ASTM Standard

Brand Name:	HAIDA
Model Number:	HD
MOQ:	1 Set
Price:	Negotiable
Packaging Details:	Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China (Mainland)

Standard:

YY0469-2004,YY/T 0969-2013,ASTMF2100,ASTMF2101,EN14683

Working Temperature:

0-50 ℃

Power Supply:

AC220V ± 10%, 50Hz

Machine Weight:

About 150kg

Host Size:

1180mm X 650mm X1300mm (WxDxH)

Supply Ability:

30 Sets per Month Haida

Highlight:

fabric checking machine

textile industry equipment

Product Description

ASTM Standard Medical Mask Bacterial Filtration Efficiency Tester

Product Introduction:

Medical Mask Bacterial Filtration Efficiency Test machine is used to detect various medical and daily protective mask materials and filter out the percentage of bacteria-containing suspended particles (BFE) under the specified flow rate.

It is suitable for the performance testing of bacterial filtration efficiency of medical surgical masks by metrological inspection departments, scientific research institutes, medical mask manufacturers and other related departments.

Test standard:

YY0469-2004,YY/T 0969-2013,ASTMF2100,ASTMF2101,EN14683 ect.

Technical Parameters:

Sampling flow	28.3L / min, resolution: 0.1L / min, accuracy: ± 2.5%
Spray flow	8 ~10L / min, resolution: 0.1L / min, accuracy: ± 5%
Peristaltic pump flow	0.006 ~3.0ml / min, resolution: 0.001ml / min, accuracy: ± 2%
Pressure before sampling flowmeter	-20 ~0KPa resolution: 0.01KPa, accuracy: ± 2%
Front pressure of spray flow meter	0 ~300KPa, resolution: 0.1KPa, accuracy: ± 2%
Aerosol chamber negative pressure	-90 ~-120Pa, resolution: 0.1Pa, accuracy: ± 1%
Working temperature	0-50 ℃
Cabinet negative pressure	> 120Pa
Data storage capacity	> 500000 sets, capacity can be expanded
High-efficiency air filtration performance	The filtration efficiency of particles above 0.3um is ≥99.995%, the filtration efficiency of particles above 0.12um is ≥99.9995%
Median mass diameter of aerosol generator	3.0 ± 0.3μm, geometric standard deviation ≤1.5
Dual 6-stage Anderson sampler capture particle size	I> 7μm, II>4.7-7μm, III >3.3-4.7μm, IV >2.1-3.3μm, V> 1.1-2.1μm, VI >0.6-1.1 μm
Aerosol chamber specifications	60cmX8.5 cmX 3cm (LxWxH)
Total number of positive control sampler particles	2200 ± 500cfu
Ventilation flow of negative pressure cabinet	≥5m3 / min
Negative pressure cabinet door size	1000mm X 730mm
Host size	1180mm X 650mm X1300mm (WxDxH)
Bracket size	1180mm X 650mm X 600mm (WxDxH), height adjustable within 10 cm
Instrument noise	<65dB (A)
Machine weight	about 150kg
Power	AC220V ± 10%, 50Hz ,power consumption: <1500W
