High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

China High Pressure Paper Testing Equipments FOR Fabric Bursting Strength supplier
High Pressure Paper Testing Equipments FOR Fabric Bursting Strength supplier High Pressure Paper Testing Equipments FOR Fabric Bursting Strength supplier High Pressure Paper Testing Equipments FOR Fabric Bursting Strength supplier High Pressure Paper Testing Equipments FOR Fabric Bursting Strength supplier

Large Image :  High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number: HD-A504-A
Power: Electric
Port: ShenZhen

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month Haida
Contact Now
Detailed Product Description
Accuracy: ± 0.5% Pressure Range: 250~5600kpa
Speed Of Compression: High Pressure 170± 10ml/min Oil: 85% Glycerin; 15% Distilled Water
Sensing Method: Pressure Transmitter Indicating Method: Digital

 High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

High Pressure Paper Testing Equipments FOR Fabric Bursting Strength


Specifications
Fabric Bursting Strength Testing Machine
1.High quality with reasonable price
2.One year free after-sale service
3.Up to TAPPI-T804,AS


The product Description:
Fabric Bursting Strength Testing Machine is fit for products which are packaged by corrugated paper such as electronic instruments, electric ware, hardwares, bike, valise, food, shoe, furniture etc, to test the bursting-resistance strength of paper box; it can also test cloth and synthetic leather. The GT-7013-ADP type of bursting strength tester is adapted with signal output of pressure. While specimen is breaking, the max. breaking value will be kept with the alarm buzzer & alert light automatically. Its Accuracy has promoted 20 times more than the traditional gauge.
High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

The parameters:


Model

HD-A504

Capacity  (Optional)

High Pressure 0~100 Kg/ cm^2 (0.1kg/cm^2)

Unit (sitchable)

Kpa, psi, kg/cm^2

Accuracy

± 0.5%

Pressure Range

250~5600kpa

Speed of Compression

High Pressure 170± 10ml/min

Specimen Clamping Force

>690kpa

Oil

85% Glycerin; 15% Distilled Water

Sensing method

Pressure Transmitter

Indicating Method

Digital

Display

LCD

Material of the Ring

Stainless Steel SUS304

Opening in Upper Clamp

31.5 ± 0.05 mm Diameter

Opening in Lower Clamp

31.5 ± 0.05 mm Diameter

Motor

Anti-vibration Motor 1/4 HP

Operation Method

Semi-automatic

Dimension (L×W×H)

430×530×520 mm

Weight

Approx. 64 kg

Power

1 , AC220± 10%, 50 Hz

Power Capacity

120W

Standard Configuration

Rubber Membrane 1 piece, Spanner 1 set, Correction Shim 10 sheets, Glycerin 1 bottle

Optional Configuration

Printer

Standard

JIS-L1004, L1018, L1031, K6328, P8131, P8112
ASTM-D2210; TAPPIT403TS-63
ISO2759-2001; GB/T1539


More Related Product Welcome to Click Here
Haida Burst Strength Tester.pdf

The introduction of Haida
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.

High Pressure Paper Testing Equipments FOR Fabric Bursting Strength
Packaging & Shipping:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.

High Pressure Paper Testing Equipments FOR Fabric Bursting Strength
