Providing Coordinate Optical Measuring Equipment, Optical Profile Measurement Instrument

China Providing Coordinate Optical  Measuring Equipment,  Optical Profile  Measurement Instrument supplier
Providing Coordinate Optical  Measuring Equipment,  Optical Profile  Measurement Instrument supplier Providing Coordinate Optical  Measuring Equipment,  Optical Profile  Measurement Instrument supplier Providing Coordinate Optical  Measuring Equipment,  Optical Profile  Measurement Instrument supplier

Large Image :  Providing Coordinate Optical Measuring Equipment, Optical Profile Measurement Instrument

Product Details:

Place of Origin: China
Brand Name: Haida
Model Number: HD-HB12

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD13,223
Packaging Details: Strong wooden case package
Delivery Time: 15 days after received deposit
Payment Terms: Full payment before delivery
Supply Ability: 80 set per mouth
Contact Now
Detailed Product Description
Power: Electronic Product Name: Optical Measuring Devices
Rotation Range: 0~360° Magnification: 10 X,20 X,50 X,100 X
Measuring Range: X=200 , Z=100 ; Y=75( Focusing ) Data Processing System: DP300 Multi-function Data Processing System

Providing Coordinate Optical Measuring Equipment, Optical Profile Measurement Instrument



Equipment discription:



This Coordinate Projector is a set of optical, mechanical, electrical, computer integration, high precision optical measuring instruments. It can efficiently detect a variety of complex shape the contours of the workpiece size and surface status, such as templates, punching pieces, cams, threads, gears, form cutter and other tools, cutting tools and parts.


Applicable industry:



This Coordinate Projector is widely used in machinery, molds, tools, instruments, electronics, light industry, measuring rooms and workshops are essential for a kind of test measurement equipment.



Technical parameter:



Model HD-HB12 Coordinate Projector HD-HB16 Coordinate Projector
Projection screen Φ330mm Φ425mm
Rotation range:0~360° ; Rotation Digital Resolution: 1′or 0.01°
Mirror matter Magnification 10 X ( Necessary ) 20X
(Option)
50X
( Option )
100X ( Option ) 10X
( Necessary )
20X
( Option )
50X
( Option )
100X ( Option )
Working distance: 77.7 44.3 38.4 25.3 103.9 95.1 65.7 35.0
Field of view in object : Φ30 Φ15 Φ6 Φ3 Φ40 Φ20 Φ8 Φ4
Table Size 408 X 126 408 × 126
Measuring range X=200 , Z=100 ; Y=75( Focusing ) X=200 , Z=150 ; Y=75( Focusing )
  X, Z-axis digital display resolution: 0.0005mm, coordinate indication error ≤ (3 + L/200) μm
Data processing system DP300 multi-function data processing system, all the Chinese showed they can do more sampling, coordinate rotation, point. Line. Circle. Distance. Angle measurement
Lighting Transmission 24V 150W, reflecting 24V 150W (with halogen lamp)
Power 110V/220V(AC),50Hz/60Hz ,Total power 400W
Size (L×W×H) 1147× 556 × 964 (L×W×H)1360X580X1170
Weight 200Kg 200Kg
Options Micro-printer, optical Edge Detector, M2D software; detailed description see Annex projector.







































































About Haida



Introduction:


HAIDA INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 24 years. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.



Why choose us?


1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2.Excellent After sale Service:
18 months warranty. Besides, we can help you to repair your problem controller freely, Free replacement parts, even it's not from our factory's. What you need to do is to send us the controller.We can offer operation video and English operation muanual. We can provide video-con
3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
4.Good Packaging:
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
