| Spray Water Pressure: | 80~100bar (8000~10000Kpa) | Water Flow: | 14~16L/min |
|---|---|---|---|
| Spray Water Distance: | 10~15cm | Spray Water Angle: | 0°, 30°, 60°, 90°, Each Angle Spray For 30 Seconds |
| Water Spray Interval Time: | 30 Seconds (adjustable) | Controller: | PLC Touch Screen |
| High Light: | environmental testing equipment,environmental testing machine |
||
Ipx3 Ipx4 Standard Automatic Salt Spray Corrosion Test Chamber
Product Introduction:
Rain test chamber is suitable for the test of adaptability and reliability of electrical and electronic products, materials and parts under the conditions of rain and temperature.Also can be used for external lighting and signal equipment and automotive lamp enclosure protection.This product adopts scientific design, so that the equipment can simulate the realistic dripping, drenching, splashing, spraying and other environments.The adoption of comprehensive control system and frequency conversion technology makes it possible to automatically adjust the rotation Angle of rainfall sample frame, the swing Angle of water spray pendulum and the swing frequency of water spray.
Standard Features:
| Item | Specification |
| Internal dimension(W*D*H) | 1000*1000*1000mm(can be customized) |
| External dimension(W*D*H) | 1500*1100*1700mm |
| Oscillating tube | Radius 400mm |
| Oscillating angle | IPX3: spray ±60° from vertical line to each side, total 120° IPX4: spray ±180° from vertical line to each side, total 360° |
| Oscillating speed | IPX3: 2*120° for 4s IPX4: 2*360° for 12s |
| Spray nozzle | Diameter: 0.4mm, removable Ensure the water sprays in a line and without tolerance |
| Distance between two nozzles | 50mm |
| Turntable dimension | 500mm |
| Turntable rotation speed | 1-3 cycles/min |
| Water flow of each nozzle | 0.07 L/min +5% |
| Test duration | 1~999,999min, adjustable |
| Pressure gauge | 80-150Kpa |
| Material | Chamber - Stainless steel ; Spray nozzle - Brass |
Application & features:
1. To be used in testing external lighting and signal device and vehicle lamps shell protection.
2. Cyclic test includes conditions: heating, watering
3. The internal chamber has lighting device
4. Rain time, rain interval time and rainfall strength can be adjusted and controlled separately.
