Electronic Aluminum Furniture Testing Machines for Pressure Tester

Electronic Aluminum Furniture Testing Machines for Pressure Tester
Electronic Aluminum Furniture Testing Machines for Pressure Tester Electronic Aluminum Furniture Testing Machines for Pressure Tester Electronic Aluminum Furniture Testing Machines for Pressure Tester Electronic Aluminum Furniture Testing Machines for Pressure Tester

Large Image :  Electronic Aluminum Furniture Testing Machines for Pressure Tester

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number: HD-T406
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month Haida
Detailed Product Description
Max Capacity: 100kg Plane Plate: Holes Diameter 6mm , Space 20mm
Speed: ( 70 ± 5 ) Times Per Minute . ( Adjustable ) Counter: 6 Digits Cycle Counter For Test Cycle Setting
Height Adjustable: After Finish To Test Specified Times , The Below Plate Can Go Up Automatically To Continue Test . Display: LCD
High Light:

furniture testing equipment

,

impact testing machine

Electronic Aluminum Furniture Testing Machines for Pressure Tester



Introduction :

The machine is used to test Foil fatigue by repeating indentation of a test piece by an indentor smaller in area than the test piece , the maximum load reached during each cycle being kept within specified limits . After finish test , check the determination of indentation hardness characteristics according to 1S0 2439 test standards .



Electronic Aluminum Furniture Testing Machines pressure tester



Parameters :

Max capacity 100kg
Plane plate Holes diameter 6mm , space 20mm
Indentor Having an overall diameter of 250 mm± 1 mm with a 25 mm± 1 mm radius at its lower edge , provided with a device for applying a maximum force of 750 N ± 20 N during one loading cycle .
Speed ( 70 ± 5 ) times per minute . ( adjustable )
Sample size Test pieces shall be right parallelepipeds having sides of length 380 mm± 20 mm and a thickness of 50 mm± 2 mm .
Counter 6 digits cycle counter for test cycle setting
Height adjustable After finish to test specified times , the below plate can go up automatically to continue test .
Display LCD
Dimension 760×780×1350mm
Power AC220V±10% , 50/60Hz , single phase



Different Models of The Machine



Electronic Aluminum Furniture Testing Machines for Pressure Tester 0Electronic Aluminum Furniture Testing Machines for Pressure Tester 1

Electronic Aluminum Furniture Testing Machines for Pressure Tester 2Electronic Aluminum Furniture Testing Machines for Pressure Tester 3
