Furniture Testing Machines Automatic Foam Compression Hardness Testing Machine Price HD-F750A

China Furniture Testing Machines Automatic Foam Compression Hardness Testing Machine Price HD-F750A supplier
Furniture Testing Machines Automatic Foam Compression Hardness Testing Machine Price HD-F750A supplier Furniture Testing Machines Automatic Foam Compression Hardness Testing Machine Price HD-F750A supplier

Large Image :  Furniture Testing Machines Automatic Foam Compression Hardness Testing Machine Price HD-F750A

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number: HD-F750A

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month Haida
Contact Now
Detailed Product Description
Capacity: 200kg Unit: Kgf\N\Lbf
Max Stroke: 1200mm (including Fixture) Test Speed: 0.1-500mm / Min
Motor: Panasonic 400W Servo Motor Screw: Imported Ball Screw
Power: Single, 220V Weights: 150kg
Model: HD-F750A
High Light:

fatigue testing equipment

,

impact testing machine

Automatic Foam Testing Machine Price HD-F750A



APPLICATIONS& TEST PURPOSE
The machine is used to test material compressed indentation hardness, such as sponge, foam and other porous elastic. Put specimen under pressure plate, the plate compress the specimen with a specify speed until the national standard require concavity, the load cell feedback the pressure to computer, it processing and display, then measure the indentation hardness of sponge, foam and other materials.

DESIGN STANDARD: ASTM D 3574

STANDARD FEATURES



  Parameter
Capacity Sensor 100KG-2T
Motor Panasonic 400W servo motor
Drive 400w servo drive
Screw Imported ball screw
Control mode Computer control, windows mode operation
Speed Speed adjustable (computer adjusted) 0.1-500mm / min
Maximum stroke 1200mm (including fixture)
Span ≤400mm
Load resolution 1 / 250,000
Load accuracy ≤0.5%
Unit switching gf / kgf / N // kN / LBf / W / T
Dimensions (L * W * H) 880 * 510 * 1490mm;
Weight about 150Kg
Power supply 1∮, AC 220V
Configuration (Pull-up) Fixture is standard according to customer's sample, (Down-pressure) includes 200mm diameter pressure plate and 380mmX380mm tray with holes
