Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber

Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber
Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber
video play

Large Image :  Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber

Product Details:
Place of Origin: Guangdong, China (Mainland)
Brand Name: HAIDA
Certification: ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number: HD-B609B-S
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month Haida
Contact Now
Detailed Product Description
Accuracy: ±0.5% Capacity: 5, 10, 20, 50, 100,150,200kg
Elongation Accuracy: 0.001mm Max. Stroke: 900mm (including Fixture)
Motor: Panasonic Servo Motor Power: 1∮, AC220V, 50HZ
Sensor: Celtron Load Cell|load Cell Test Speed: 0.1-500mm/min (adjustable )
Type: Tensile Tester Port: Panasonic Servo Motor
High Light:

universal tensile testing machine

,

compressive strength testing machine

Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber



Application:

  1. Tested sample: plastic films, laminated materials, adhesive tapes, adhesive bandage (plaster), release paper, plastic films, leather, rubber & plastic, paper, fiber, etc.
  2. Different test with different grips: tensile, peel, tear, heat seal, adhesive, bend and open force.
  3. Deformation under defined load: Test deformation under defined load of tested sample
  4. Load under defined deformation: Test load under defined deformation of tested sample
  5. Software can issue word/excel report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.

Film/Plastic Film:

  • ASTM D882: Tensile Test
  • ASTM F1306: Puncture Test
  • ASTM D1938: Trouser Tear Test
  • ASTM D2732: Thermal Shrinkage Test
  • ASTM D1709, ISO 7765-1: Free-Falling Dart Method
  • ASTM D1894: Static and Kinetic Coefficients of Friction
  • ASTM D1424, ASTM D1922, ISO 1974: Elmendorf Tearing Strength Test

Main Technical Parameter:

Items

Specification

Sensor

Celtron load cell

Capacity

5, 10, 20, 25, 50, 100, 150,200kg

Unit Switchover

G, KG, N, LB

Display Device

LCD or PC

Resolution

1/250,000

Load Accuracy

≤0.5%

Max. Stroke

900mm (including fixture)

Test Speed

0.1-500mm/min (adjustable )

Motor

Panasonic Servo Motor

Screw

High Precise Ball Screw

Elongation Accuracy

0.001mm

Power

1∮, AC220V, 50HZ

Weight

Approx.70kg

Accessories

One set tensile clamp, one set Lenovo computer, one piece English software CD, one piece operation video CD, one piece English user manual
Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber 0



Electric Tensile Strength Test Machine With Panasonic Servo Motor For Metal / Rubber 1


Tag:

universal tensile testing machine,

electronic universal testing machine,

compressive strength testing machine
